Full Color Window Sign
Temporary Emergency Sign
SKU: TES-EMERG
Warranty
3 years warranty on parts
Control
PRO-LED Cloud (phone or computer)
Made to order — not ready-made
About 1 week to manufacture, then plus shipping time. Shipping-day estimates at checkout are transit time only, after your sign is built and packaged.
Download datasheet
Product Specifications
Temporary Emergency Sign — school / facility emergency LED display system based on PRO-LED project School Emergency LED Sign System (project code PL268).
What it does
- Shows normal messages (clock / custom content) by default
- Switches to emergency messaging via dry-contact test switch (OFF = normal, ON = emergency)
- Content updated with PRO-LED Cloud control (phone or computer), using the included emergency-sign template
Key specs
| Display resolution | 320 × 192 pixels (5 mm pitch, 63" W × 37¾" H Premium Duty cabinet, 53P) |
| Control | PRO-LED Cloud control (phone or computer) |
| Power | AC 110V input; DC 24V control circuit (max ~50W on control section) |
| Network | PC port — wire to building network (same network as admin office PC) |
| Sign link | Display port — waterproof RJ45 to LED sign |
| Emergency input | Dry contact (X24-3 / X24-8) for emergency message trigger |
| Content | Keep Normal Status on top, then Emergency — do not delete those programs in the control software |
Available Sizes (PRO-LED Premium Duty Cabinets)
Built on the 5' x 3' Premium Duty cabinet (320 × 192 pixels). Each sign is built on a PRO-LED Premium Duty outdoor cabinet. Sizes are cabinet dimensions; -W = single sided, -D = double sided.
| Model | Cabinet size | Pixel pitch | Pixels (W × H) |
|---|---|---|---|
| 53P-W / 53P-D | 63" W × 37¾" H | 5 mm | 320 × 192 |
All Premium Duty cabinets: full color SMD, ≥6,500 nits, ≥3,840 Hz refresh, IP67, -40 °C to +60 °C, aluminum cabinet, MET Canada certified, 5-year warranty. Final size and layout are confirmed with your quote.
Included with the system package
- Emergency control cabinet / wiring per School Emergency Wiring Diagram
- Default emergency-sign program file, pre-loaded
- How-to guide for updating contents
Pricing: contact info@proledsigntech.com for a quote.
Technical Specifications
| Sign Type | Full Color Window Sign |
|---|---|
| Brightness | 4500 nits |
| Control Method | PRO-LED Cloud (phone or computer); PC software (offline/USB) also supported |
| Warranty | 3 years warranty on parts |
| Power | 110V AC (standard plug) |
| Made In | Canada (with global components) |
How It Works
Open PRO-LED Cloud
Sign in at cloud.proledsigntech.com on your phone or computer.
Find Your Sign
Sign in at cloud.proledsigntech.com/portal. PRO-LED links your sign to your account.
Type Your Message
Supports text, effects, and scheduling.
Send & Display Instantly
Changes appear in seconds.
You can also manage programs from PRO-LED Cloud on your phone or computer, or with PC software (offline/USB) on Windows. Download software →
